IP-COM M20-8G-PoE
|
|
Dimensions
|
177.5 x 104 x 26 mm |
Application Scenario
|
Enterprise, Office |
Operation mode
|
Router Mode, AC Mode |
Performance Parameters
|
|
Max. Client Capacity
|
150 |
Recommended Client Capacity
|
100 |
Recommended broadband
|
1000Mbps |
Max. New Sessions
|
4000 |
Max. Concurrent Sessions
|
49000 |
NAT (Static IP)
|
940Mbps/930Mbps |
NAT(DHCP)
|
941Mbps/932Mbps |
NAT(PPPoE)
|
914Mbps/924Mbps |
AP Management
|
Router mode: 128 AC mode: 256 |
VLAN
|
4 |
Hardware Parameters
|
|
CPU
|
Dual Core,1.0GHz |
RAM
|
128 MB |
FLASH
|
16 MB |
Ports
|
9x GE (Max. 4 WAN, Max. 8 LAN) |
PoE outport
|
802.3af/at on LAN1-8 |
PoE Budget
|
95W |
Button
|
Reset Button |
USB
|
1x USB |
Standards and Protocols
|
IEEE 802.3, 802.3u, 802.3x, TCP/IP, DHCP, ICMP, NAT, PPPoE, NTP, HTTP, DDNS |
Power Supply
|
51V DC, 2A Adapter |
Software Parameters (Router)
|
|
AP Management
|
128APs |
DHCP Server
|
DHCP Server(User/AP),DHCP Reservation |
Wireless Policy
|
AP Group,SSID Policy,RF Policy,Vlan Policy,maintenance policy,Alarm Policy,Deployment Policy |
Fast roaming
|
802.11k,v,r |
IPTV
|
IPTV Policy |
ACL
|
IP/MAC/URL/PORT |
Bandwidth Control
|
Based on single user, user group, smart bandwidth control |
VPN
|
IPSec, PPTP, L2TP |
Virtual Server
|
DMZ, DDNS, DNS Hijacking,IP Hijacking,UPNP,Port Mirroring,Port Mapping,DNS Cache |
IPV6
|
Support |
WAN Load Balancing
|
Intelligent Load Balancing,Customize |
Routing
|
Static Routing,Policy Routing |
Security
|
IP-MAC binding, Block Ping from WAN,DDoS Attack Defense,ARP Attack Defense,Binary Association |
System Tools
|
ntp,Scheduled reboot, Diagnosis |
system log
|
system log,Operating log,Running log |
System Account
|
Administrator,Visitor,Login IP Address Limit |
Upgrade
|
Local,Online |
Maintenance
|
Restore,Backup,Remote WEB Management |
Management
|
http/https,Profi Cloud,Profi APP |
Software Parameters (AC)
|
|
AP Management
|
256APs |
DHCP Server
|
DHCP Server(User/AP),DHCP Reservation |
Wireless Policy
|
AP Group,SSID Policy,RF Policy,Vlan Policy,maintenance policy,Alarm Policy,Deployment Policy |
Fast roaming
|
802.11k,v,r |
IPTV
|
IPTV Policy |
Security
|
Block Ping from WAN,DDoS Attack Defense,ARP Attack Defense,Binary Association |
System Tools
|
ntp,Scheduled reboot, Diagnosis |
system log
|
system log,Operating log,Running log |
System Account
|
Administrator,Visitor |
Upgrade
|
Local,Online |
Maintenance
|
Restore,Backup,Remote WEB Management |
Management
|
http/https,Profi Cloud,Profi APP |
Other Parameters
|
|
Environment
|
Operating Temperature: -10℃-45°C Operating Humidity:10%-90% RH, non-condensing Storage Temperature: -40°C-70°C Storage Humidity: 5%-90% RH, non-condensing |
