ETHERNET
|
|
|
WAN
|
1x WAN (can be configured to LAN) 10/100/1000 Mbps, comply IEEE 802.3, IEEE 802.3u, 802.3az standards, supports auto MDI/MDIX crossover |
|
LAN
|
3x LAN ports, 10/100/1000 Mbps, comply IEEE 802.3, IEEE 802.3u, 802.3az standards, supports auto MDI/MDIX crossover |
|
NETWORK
|
|
|
Routing
|
Static routing, Dynamic routing (BGP, OSPF v2, RIP v1/v2) |
|
Network protocols
|
TCP, UDP, IPv4, IPv6, ICMP, UDP, NTP, DNS, HTTP, FTP, SMTP, TLS, ARP, VRRP, PPP, PPPoE, UPNP, SSH, DHCP, Telnet, SMPP |
|
VoIP passthrough support
|
H.232 and SIP-alg protocol NAT helpers, allowing proper routing of VoIP packets |
|
Connection monitoring
|
Ping Reboot, Periodic Reboot, LCP and ICMP for link inspection |
|
Firewall
|
Port forward, traffic rules, custom rules |
|
DHCP
|
Static and dynamic IP allocation, DHCP Relayd |
|
QoS
|
Traffic priority queuing by source/destination, service, protocol or port, WMM, 802.11e |
|
DDNS
|
Supported >25 service providers, others can be configured manually |
|
Network backup
|
VRRP |
|
SSHFS (optional)
|
Possibility to mount remote file system via SSH protocol (not available in standard FW) |
|
MONITORING & MANAGEMENT
|
|
|
WEB UI
|
HTTP, status, configuration, FW update, CLI ,troubleshoot, event log, system log, kernel log |
|
FOTA
|
Firmware update from server, automatic notification. |
|
SSH
|
SSH (v1, v2) |
|
TR-069
|
OpenACS, EasyCwmp, ACSLite, tGem, LibreACS, GenieACS, FreeACS, LibCWMP, Friendly tech, AVsystems |
|
SNMP
|
SNMP (v1, v2, v3), SNMP trap |
|
JSON-RPC
|
Management API over HTTP |
|
MODBUS
|
MODBUS TCP status/control |
|
RMS
|
Teltonika Remote Management System (RMS) |
|
SYSTEM CHARACTERISTICS
|
|
|
CPU
|
Quad-core ARM Cortex A7, 717MHz |
|
RAM
|
256MB, DDR2 |
|
FLASH memory
|
256MB SPI Flash |
|
FIRMWARE / CONFIGURATION
|
|
|
WEB UI
|
Update FW from file, check FW on server, configuration profiles, configuration backup |
|
FOTA
|
Update FW/configuration from server |
|
RMS
|
Update FW/configuration for multiple devices |
|
Keep settings
|
Update FW without losing current configuration |
|
FIRMWARE CUSTOMIZATION
|
|
|
Operating system
|
RutOS (OpenWrt based Linux OS) |
|
Supported languages
|
Busybox shell, Lua, C, C++ |
|
Development tools
|
SDK package with built environment provided |
|
INPUT/OUTPUT
|
|
|
Input
|
1 x Digital Input (Non-isolated, Logic low 0...+5V, Logic high +8...+40V) |
|
Output
|
1 x Digital Output (open collector type, 30V@0.3A) |
|
Events
|
EMAIL, RMS |
|
USB
|
|
|
Data rate
|
USB 2.0 |
|
Applications
|
Samba share, custom scripts |
|
External devices
|
Possibility to connect external HDD, flash drive, additional modem, printer |
|
Storage formats
|
FAT, FAT32, NTFS |
|
POWER
|
(zasilacz w zestawie) |
|
Connector
|
4 pin industrial DC power socket |
|
Input voltage range
|
9 - 50 VDC, reverse polarity protection, voltage surge/transient protection |
|
PoE (passive)
|
Passive PoE. Possibility to power up through LAN port, not compatible with IEEE802.3af and 802.3at standards |
|
Power consumption
|
11W Max. |
|
PHYSICAL INTERFACES (PORTS, LEDS, BUTTONS)
|
|
|
Ethernet
|
4x RJ45 ports, 10/100/1000 Mbps |
|
Status LEDs
|
3x connection status LEDs, 5x connection strength LEDs, 8x LAN status LEDs, 3x WAN status LEDs, 1x Power LED |
|
Power
|
4 pin industrial DC power socket |
|
USB
|
USB A socket for external devices |
|
Reset
|
Reset/restore to default button |
|
PHYSICAL SPECIFICATION
|
|
|
Casing material
|
Full aluminium housing |
|
Dimensions
|
115 x 95 x 32 mm |
|
Weight
|
357 g |
|
Mounting options
|
DIN rail (can be mounted on two sides), flat surface placement |
|
OPERATING ENVIRONMENT
|
|
|
Operating temperature
|
-40 C to 75 C |
|
Operating humidity
|
10% to 90% non-condensing |
|
Ingress Protection Rating
|
IP30 |
