MODULE
|
|
|
Name
|
MeiG SLM320-L16A, MeiG SLM320-PE2C, Teltonika TM2500 |
|
Technology
|
LTE(CaT1)/2G(GSM/GPRS)/GNSS/BLUETOOTH |
|
GNSS
|
|
|
GNSS
|
GPS, GLONASS, GALILEO, BEIDOU, SBAS, QZSS, DGPS, AGPS |
|
Receiver
|
33 channel |
|
Tracking sensitivity
|
-165 dBM |
|
Accuracy
|
< 3 m |
|
Hot start
|
< 1 s |
|
Warm start
|
< 25 s |
|
Cold start
|
< 35 s |
|
CELLULAR
|
|
|
Technology
|
LTE Cat 1, GSM |
|
Bands 2G
|
MeiG SLM320-PE2C: GSM: B2/B3/B5/B8 MeiG SLM320-L16A: GSM: B2/B3/B5/B8 |
|
Bands 4G
|
MeiG SLM320-PE2C: B1/B3/B7/B8/B20/B28 LTE-TDD:B38/B40/B41 MeiG SLM320-L16A: LTE FDD: B1/B2/B3/B4/B5/B7/B8/B20/B28 LTE-TDD:B40 |
|
Transmit power
|
Class 4 for GSM850/900: 23±2dBm Class 1 for GSM1800/1900: 20±2dBm Class 3 for LTE-TDD: 23±2.7dBm Class 3 for LTE-FDD: 23±2.7dBm |
|
Data transfer
|
LTE: LTE FDD: Max 10Mbps (DL)/Max 5Mbps (UL) LTE TDD: Max 8Mbps (DL)/Max 2Mbps (UL) GSM: GPRS: Max 85.6Kbps (DL)/Max 85.6Kbps (UL) |
|
Data support
|
SMS (text/data) |
|
POWER
|
|
|
Supply voltage range
|
10 - 30 V DC with overvoltage protection |
|
Back-up battery
|
3170 mAh Li-Ion battery 3.7 V (0.63 Wh) |
|
Power consumption
|
At 12V < 3 mA (Ultra Deep Sleep) At 12V < 5 mA (Deep Sleep) At 12V < 16 mA (Online Sleep) At 12V < 18 mA (GPS Sleep) At 12V < 33 mA (nominal with no load) At 12V < 2A Max. (with full Load / Peak) |
|
BLUETOOTH
|
|
|
Specification
|
4.0 + LE |
|
Supported peripherals
|
Temperature and Humidity sensor, Inateck Barcode Scanner, Universal BLE sensors support |
|
OBD INTERFACE
|
|
|
Data
|
HS CAN, MS CAN, SW CAN, K-line |
|
Data reading
|
OEM Fuel level, odometer and up to 32 vehicle onboard parameters, supported OBD protocols: ISO 9141-2 (5 baud init, 10.4 kbaud) ISO 14230-4 KWP (5 baud init, 10.4 kbaud) ISO 14230-4 KWP (fast init, 10.4 kbaud) ISO 15765-4 CAN (11 bit ID, 250 kbaud) ISO 15765-4 CAN (11 bit ID, 500 kbaud) ISO 15765-4 CAN (29 bit ID, 250 kbaud) ISO 15765-4 CAN (29 bit ID, 500 kbaud) ISO 14229 (UDS) J2819 (VW TP2.0) |
|
INTERFACE
|
|
|
Connection
|
OBDII Socket |
|
GNSS antenna
|
Internal High Gain |
|
GSM antenna
|
Internal High Gain |
|
USB
|
2.0 Micro-USB |
|
LED indication
|
2 status LED lights |
|
SIM
|
Micro-SIM |
|
Memory
|
- |
|
PHYSICAL SPECIFICATION
|
|
|
Dimensions
|
67,2 x 49,6 x 25 mm (L x W x H) |
|
OPERATING ENVIRONMENT
|
|
|
Operating temperature (without battery)
|
-40 °C to +85 °C |
|
Storage temperature (without battery)
|
-40 °C to +85 °C |
|
Operating humidity
|
5% to 95% non-condensing |
|
Ingress Protection Rating
|
IP41 |
|
Battery charge temperature
|
+10 °C to +45 °C |
|
Battery discharge temperature
|
-20 °C to +60 °C |
|
Battery storage temperature
|
-20 °C to +45 °C for 1 month -20 °C to +35 °C for 6 months |
|
FEATURES
|
|
|
Sensors
|
Accelerometer |
|
Scenarios
|
Green Driving, Over Speeding detection, Jamming detection, GNSS Fuel Counter, Excessive Idling detection, Unplug detection, Towing detection, Crash detection, Auto Geofence, Manual Geofence, Trip |
|
Sleep modes
|
GPS Sleep, Online Deep Sleep, Deep Sleep, Ultra Deep Sleep |
|
Configuration and firmware update
|
FOTA Web, FOTA, Teltonika Configurator (USB, Bluetooth), FMBT mobile application (Configuration) |
|
SMS
|
Configuration, Events, Debug |
|
GPRS commands
|
Configuration, Debug |
|
Time Synchronization
|
GPS, NITZ, NTP |
|
Fuel monitoring
|
OBD II |
|
Ignition detection
|
Accelerometer, External Power Voltage, Engine RPM |
|
Certifications & Approvals
|
|
|
Regulatory
|
CE RED, E-Mark, RCM, KC, NCC |
