MODULE
|
|
|
Name
|
FMC920-QJIB0: Quectel EG915U-EU with Teltonika TM2500 FMC920-QKIB0: Quectel EG915U-LA with Teltonika TM2500 |
|
Technology
|
LTE Cat 1/GSM/GPRS/GNSS/BLUETOOTH |
|
GNSS
|
|
|
GNSS
|
GPS, GLONASS, GALILEO, BEIDOU, SBAS, QZSS, DGPS, AGPS |
|
Receiver
|
33 channel |
|
Tracking sensitivity
|
-165 dBM |
|
Accuracy
|
< 2.5m CEP |
|
Hot start
|
< 1 s |
|
Warm start
|
< 25 s |
|
Cold start
|
< 35 s |
|
CELLULAR
|
|
|
Technology
|
LTE Cat 1, GSM |
|
Bands
|
2G: FMC920-QJIB0: GSM: B2/B3/B5/B8 FMC920-QKIB0: GSM: B2/B3/B5/B8 4G: FMC920-QJIB0: LTE FDD: B1/B3/B7/B8/B20/B28 FMC920-QKIB0: LTE FDD: B2/B3/B4/B5/B7/B8/B28/ B66 |
|
Data transfer
|
LTE: LTE FDD : Max 10Mbps (DL)/Max 5Mbps (UL) LTE TDD: Max 85.6 Mbps (DL)/Max 85.6 Mbps (UL) GSM: GPRS: Max 85.6Kbps (DL)/ Max 85.6Kbps (UL) |
|
Data support
|
SMS (text/data) |
|
POWER
|
|
|
Input voltage range
|
10–30 V DC with overvoltage and reverse polarity protection |
|
Back-up battery
|
170 mAh Li-Ion battery (0.63 Wh) |
|
Power consumption
|
At 12V < 2 mA (Ultra Deep Sleep) At 12V < 3 mA (Deep Sleep) At 12V < 8 mA (Online Sleep) At 12V < 12 mA (GPS Sleep) At 12V < 28 mA (nominal) |
|
BLUETOOTH
|
|
|
Specification
|
4.0 + LE |
|
Supported peripherals
|
Temperature and Humidity sensor, Inateck Barcode Scanner, Universal BLE sensors support |
|
INTERFACE
|
|
|
Digital Inputs
|
1 |
|
Digital Outputs
|
1 |
|
Analog Inputs
|
1 |
|
GNSS antenna
|
Internal High Gain |
|
Cellular antenna
|
Internal GSM High Gain |
|
USB
|
2.0 Micro-USB |
|
LED indication
|
2 status LED lights |
|
SIM
|
Micro-SIM |
|
Memory
|
128MB internal flash memory |
|
PHYSICAL SPECIFICATION
|
|
|
Dimensions
|
79 x 43 x 12 mm (L x W x H) |
|
Weight
|
54 g |
|
OPERATING ENVIRONMENT
|
|
|
Operating temperature
|
with battery -20 °C to +40 °C without battery -40 °C to +85 °C |
|
Storage temperature (without battery)
|
-40 °C to +85 °C |
|
Operating humidity
|
5% to 95% non-condensing |
|
Ingress Protection Rating
|
IP54 |
|
Battery charge temperature
|
0 °C to +45 °C |
|
Battery discharge temperature
|
-20 °C to +60 °C |
|
Battery storage temperature
|
-20 °C to +45 °C for 1 month -20 °C to +35 °C for 6 months |
|
FEATURES
|
|
|
Sensors
|
Accelerometer |
|
Scenarios
|
Green Driving, Over Speeding detection, Jamming detection, GNSS Fuel Counter, DOUT Control Via Call, Excessive Idling detection, Unplug detection, Towing detection, Crash detection, Auto Geofence, Manual Geofence, Trip |
|
Sleep modes
|
GPS Sleep, Online Deep Sleep, Deep Sleep, Ultra Deep Sleep |
|
Configuration and firmware update
|
FOTA WEB, FOTA, Teltonika Configurator (USB, Bluetooth), FMBT mobile application (Configuration) |
|
SMS
|
Configuration, Events, DOUT control, Debug |
|
GPRS commands
|
Configuration, DOUT control, Debug |
|
Time Synchronization
|
GPS, NITZ, NTP |
|
Fuel monitoring
|
LLS (Analog), OBDII dongle |
|
Ignition detection
|
Digital Input 1, Accelerometer, External Power Voltage, Engine RPM (OBDII dongle) |
|
CERTIFICATION & APPROVALS
|
|
|
Regulatory
|
FMC920-QJIB0: CE/RED, E-Mark, CITC, TRA, RCM, RoHS, REACH FMC920-QKIB0: RCM, RoHS, Anatel (in progress) |
